Honda CBR1000RR 2012 - 2013 DIY Windscreen Install 1 426 install SPORTBIKE SADDLES & WINDSCREENS Fig 3. Locate the windscreen fairing slot, windscreen retention pegs and bottom wellnut fairing frame before you install your new ZG windscreen. Caution: Those retention pegs are fragile and will break off if forced.
FIG1 Helpful hints: Use metric tools, clean hands, put the bike on a stand. Do not pry on the screen excessively, as it can break without warning. Installation Instructions for Honda CBR 1000RR 2012 - 2013 Thank you for purchasing Zero Gravity windscreen, which has been designed and manufactured to give years of safe & fun riding. These instructions give you an in-depth look at the installation process. To receive further assistance or parts please e-mail techinfo@zerogravity-racing.com. PLEASE READ BEFORE MOUNTING YOUR WINDSCREEN FIG2 FIG3 FIG4 Fig 1.
Oct 18, 2018 - honda cbr1000rr 2004 2005 service repair manual pdf honda cbr 1000 rr 2004 service manual honda cbr 1000 rr 2004 service manual. Good day, pay for a manual honda cbr 1000 rr 2007 and received a 2008 that is not right, I want my money the debolucion or download the correct manual. Pham hong July 7, 2016 at 9:53 pm bad day, pay for a manual honda cbr 1000 rr 2006 and received a 2008 that is not right, I want refund or download the correct manual.
Honda Cbr 1000 Horsepower
Loosen both mirrors. Locate both fasteners lo- cated on the inside fairing.
Be careful not to drop the mirrors or lose the nuts. Remove bottom wellnuts ( for lo- cation see Fig 2 ) first. To remove bottom wellnuts sim- ply pull wellnuts out. It’s a bit of a pull since there are two layers (windscreen & fairing frame). Once removed pull windscreen towards the back, while guiding and pushing the front windscreen.
Remove Grommet and Wellnuts and transfer them to the ZG screen. Windscreen Fairing Slot Windscreen Retention Pegs Grommet Locations Bottom Wellnut Top Wellnut Bottom Left Wellnut in place Bottom Well- nut Fairing Frame Bottom Right Wellnut NOT in place Both grommet holes are in line with pegs Fig 4. While installing the windscreen, postion ONE side of the bottom wellnut first, (Shown Bottom left side in first) and also guide the grommet holes into the pegs (Both Sides for the grommet) Be careful not too exert to much force! Removing Factory Screen Wellnut/Grommet Transfer / Front Slot Location Wellnut/Peg Overview Screen Install Left Side Tip of the screen Front Slot Location Fig 2.
Make sure to transfer all grommets and well- nuts as shown above in the same way they were in- stalled on your OEM screen. Note the location: Tip of the screen, this will be impor- tant in the install process. Caution: Tip of the screen are fragile and will break off if applied with heavy pressure.
